    Fluoroscopy Podiatry Medical X-ray Instruments

    Model NO: XR-100C Veterinary Imaging Medical X-ray Instruments
    Certification: ISO, OHSAS
    Effective Field of View: Φ 100mm
    Resolution: 45 Lp/Cm
    Maximum Detection Spacing: ≤ 280mm
    X-ray Tube Voltage: 50~80kv
    X-ray Tube Current: 0.3-0.5mA
    X-ray Leakage: <5mr/H
    Contrast: 4%
    Grayscale: Level 7
    Input Power: 60-90 Va
    Output Brightness: > 25CD/Cm2
    Power Consumption: 70va
    Power Supply: 220V±22V, 50±1Hz
    Working Temperature: 10ºC-40ºC
    Working Hmidity: ≤75%
    Lead Time: 2 Business Days Fast Dispatch
    Transport Package: Copper Alloy Suitcase/Plywood Case

    GET A QUOTE



    Instrument Features

    1: No darkroom, real-time imaging, display synchronization display, can be connected to the computer storage printing;
    2: High gain, high sensitivity, high spatial resolution, short response time;
    3: Simple design, small size, light weight, can be used by hand;
    4: Low radiation dose, safe and reliable, easy to operate.


    Product Applications

    - It is used for factory connecting wires, USB wires, earphones, die-casting parts, aluminum castings, plastic castings, die-casting parts and other electronic components. Whether the internal structure is offset or deformed; whether it is desoldered or not.

    - Adaptation to hospital surgery, especially the necessary tools for orthopedic surgeons, door, emergency, visit, ward round and surgical site X-ray fluoroscopy, closed reduction of limb fractures, fixation, needle insertion, foreign body, especially X-ray fluoroscopy and gynecological birth control ring for newborn babies and young children with the best use of slinged intramedullary nails or external fixation brackets.



    Product Description

    Juzheng Digital Portable Low Intensity XR-100C Veterinary Imaging Medical X-ray Instruments
    Veterinary Imaging Medical X-ray Instruments XR-100C

    Specifications


    Product Name Portable X-Ray Fluoroscopy Instrument
    Model# XR-100C
    Product Application The detection of Pet/Veterinary, Limbs/Orthopedic, Chip/Electronic, Pottery
    Field of View Φ 100mm
    Resolution 46 lp/cm
    Maximum Detection spacing ≤ 280mm
    X-ray Output 75 Kv/0.35 mA
    X-ray leakage <5mR/h
    Contrast 4%
    Grayscale Level 7
    Input Power 60-90 VA
    Output Brightness > 25cd/cm2
    Power Consumption 70VA
    Power Supply 220V±22V  50±1Hz
    Product Packaging Copper Alloy Suitcase
    Product Net Weight/Gross Weight 5 kg / 14kg
    Warranty Period 12 Months
