    Powder Small Particles Metal Detector

    The XR-180C-3 series Gravity Feed Free Fall / Throat Metal Detector Metal Separator is designed for inspecting powders, granules or bulk food products

    GET A QUOTE


    Product Description

    The XR-180C series Gravity Feed Free Fall / Throat Metal Detector Metal Separator is designed for inspecting powders, granules or bulk food products. The XR-180C metal detector unit with separation flap rejection system, and it is an ideal metal detection system for checking early in the production process to detect all metal contaminations before the product moves down the line, and minimising the potential cost of wastage and protecting other processing equipment. In this category the system will be having configuration ranging from 25 mm Dia., to 250 mm Diameter of pipeline, which can meet multi-application requirements. Juzheng metal detectors help you meet QS, HACCP, IFS, BRC and GMP requirements.

    Applications:XR-180C-3 is more suitable for powder and fine particles, which improves the sealing performance of pipelines
    Model# Pipeline Dia. Detection Accuracy
    (Φ mm)    		 Max. Capacity Installation
    Height     		 Temp.
     Range    		 Material
    of
    Construction
    (Φ mm/In) (Fe) (SUS) (L/H） (mm) (°C/°F)
    XR-180C-25 25/9.84'' 0.2 0.4 300 330






    -5-40°C /
    23-04°F






    Stainless
    Steel
    (SUS 304)
    XR-180C-35 35/13.78'' 0.3 0.5 400 330
    XR-180C-50 50/19.68'' 0.5 1.0 2,000 330
    XR-180C-70 70/27.56'' 0.7 1.2 5,000 330
    XR-180C-100 100/39.37'' 1.0 1.5 12,000 480
    XR-180C-120 120/47.24'' 1.2 2.0 16,000 480
    XR-180C-150 150/59.06'' 1.5 2.5 25,000 600
    XR-180C-200 200/78.74'' 2.0 3.0 40,000 920
    XR-180C-250 250/98.43'' 2.5 3.5 60,000 950
