Industrial Metal Detection Systems
Main Specifications
|
Model |
XR-980 |
XR-506 |
XR506-3 |
||||||
|
Conveyor height(can be customized) |
680mm ± 30mm |
680mm ± 30mm |
680mm ± 30mm |
||||||
|
Memory function |
100 product parameters |
207 product parameters |
207 product parameters |
||||||
|
Operation Panel Languages |
English,Spanish,Portuguese, Turkish,Japanese, Chinese |
English, Spanish, Chinese |
English, Spanish, Chinese |
||||||
|
LCD Screen |
3.2''LCD screen with push buttons |
7'' Full touchable screen |
7'' Full touchable screen |
||||||
|
Tunnel width(mm) |
400(Standard ) ;Customized(Nonstandard) |
||||||||
|
Tunnel height(mm) |
100 |
120 |
150 |
200 |
250 |
300 |
350 |
400 |
|
|
Detection sensitivity
|
Fe(mm) |
≥0.6 |
≥0.8 |
≥1.0 |
≥1.5 |
≥1.5 |
≥2.0 |
≥2.5 |
≥3.0 |
|
Non-Fe (mm) |
≥1.0 |
≥1.2 |
≥1.5 |
≥2.0 |
≥2.5 |
≥3.0 |
≥3.5 |
≥4.0 |
|
|
SUS304 (mm) |
≥1.2 |
≥1.5 |
≥2.0 |
≥2.5 |
≥3.0 |
≥3.5 |
≥4.0 |
≥4.5 |
|
|
Machine Material |
SUS304 |
||||||||
|
Conveyor belt |
Food-grade white belt |
||||||||
|
Conveyor direction |
From left to right (face to the operation panel) |
||||||||
|
Control power |
Alternating current 110V/120V/380V(+10%,-15% 50/60Hz) |
||||||||
|
Buttons |
With Emergency Stop Button & Start/Stop Buttons |
||||||||
|
Working Temperature |
0℃~40℃ |
||||||||
|
Humidity |
Below 90%Relative humidity (without condensate) |
||||||||
|
Customized service |
1.Tunnel size;2.Rejection system:Pusher,Air jet,Drop down and Diverter for optional;3.Conveyor height; 4.Conveyor direction;5.Conveyor belt:Food grade white belt,Plate chain conveyor. |
||||||||
|
Remark |
The actual performance may be subject to working environment and components of the products to be tested. |
||||||||
Features
Juzheng developed four types of metal detectors as follows:
- Pharmaceutical type
- Conveyor type
- Vertical fall type
- Pipeline type
